Polyester Fibers
Click on the arrows to sort each parameter.
Pattern Name | Weight oz/sq yard | Thickness (in) | Air Permeability (CFM) | Warp Tensile Strength (lbs) | Filling Tensile Strength (lbs) | Warp Thread Count (per in.) | Filling Thread Count (per in.) | Weave |
---|---|---|---|---|---|---|---|---|
15010 | 6.2 | 0.0136 | 46 | 210 | 205 | 39 | 40 | Plain |
15011 | 5.5 | 0.0107 | 20.4 | 174 | 156 | 70 | 63 | Plain |
15022 | 1.9 | 0.0047 | 234.6 | 109 | 94 | 101 | 89 | Plain |
15023 | 4.3 | 0.0096 | 235.6 | 210 | 195 | 66 | 70 | Basket |
15031 | 5.2 | 0.0111 | 130.6 | 164 | 145 | 64 | 57 | Twill |
15041 | 1.2 | 0.0044 | 710 | 55 | 44 | 111 | 98 | Plain |
15042 | 2.2 | 0.0093 | 437.3 | 39 | 35 | 46 | 44 | Plain |
15085 | 7.1 | 0.014 | 67.5 | 259 | 212 | 52 | 43 | Basket |
15090 | 3 | 0.0065 | 20 | 511 | 201 | 47 | 42 | Plain |
15132 | 6 | 0.0115 | 36.9 | 300 | 235 | 20 | 16 | Plain |
15144 | 3.2 | 0.0126 | 1200 | 166 | 176 | 44 | 21 | Leno |
15145 | 1 | 0.0027 | 710 | 46 | 56 | 80 | 85 | Plain |
15199 | 3.8 | 0.0099 | 379.5 | 172 | 135 | 58 | 42 | Plain |
15203 | 3.7 | 0.0069 | 27.3 | 174 | 210 | 53 | 64 | Plain |
15204 | 4 | 0.0073 | 12.5 | 184 | 221 | 57 | 66 | Plain |
15205 | 3.1 | 0.0064 | 77.4 | 168 | 161 | 51 | 49 | Plain |
15207 | 5.1 | 0.009 | 12.8 | 244 | 285 | 74 | 84 | Twill |
15239 | 4 | 0.0074 | 20.6 | 195 | 212 | 60 | 65 | Plain |
15240 | 3.1 | 0.0062 | 24.3 | 154 | 177 | 49 | 51 | Plain |
15251 | 2 | 0.0057 | 875 | 72 | 68 | 67 | 66 | Plain |
15266 | 4.3 | 0.0087 | 20.2 | 221 | 230 | 67 | 71 | Basket |
15270 | 13.5 | 0.0344 | 466.5 | 632 | 890 | 37 | 40 | Leno |
15278 | 3.5 | 0.0145 | 1000 | 187 | 191 | 48 | 23 | Leno |
15279 | 7.6 | 0.0143 | 31.2 | 332 | 293 | 57 | 48 | Plain |
15284 | 8 | 0.0174 | 216.1 | 474 | 440 | 24 | 20 | Plain |
15293 | 2 | 0.0056 | 424 | 96 | 112 | 78 | 86 | Plain |
15295 | 1.5 | 0.0046 | 710 | 70 | 82 | 97 | 108 | Plain |
15299 | 2.7 | 0.0054 | 130.1 | 126 | 115 | 88 | 82 | Plain |
15300 | 3.4 | 0.0125 | 924.4 | 128 | 119 | 43 | 41 | Plain |
15302 | 1.4 | 0.0051 | 974 | 42 | 41 | 97 | 98 | Plain |
15314 | 5.5 | 0.0095 | 2.5 | 215 | 193 | 70 | 74 | Plain |
15330 | 4.1 | 0.0098 | 323.4 | 266 | 203 | 60 | 43 | Plain |
15340 | 2.2 | 0.0055 | 147.9 | 133 | 136 | 35 | 35 | Plain |
15341 | 5.4 | 0.0113 | 36.2 | 236 | 206 | 96 | 62 | Plain |
15343 | 6.6 | 0.0149 | 14.2 | 310 | 111 | 67 | 42 | Plain |
15345 | 1 | 0.0029 | 710 | 57 | 56 | 83 | 87 | Plain |
15352 | 3.2 | 0.0075 | 152.7 | 172 | 163 | 51 | 51 | Basket |
15360 | 5.1 | 0.0096 | 47.2 | 207 | 169 | 70 | 56 | Plain |
15364 | 3.6 | 0.0054 | 3.7 | 131 | 97 | 198 | 140 | Twill |
15370 | 4.2 | 0.0103 | 31 | 197 | 171 | 51 | 57 | Basket |
15376 | 5.4 | 0.0119 | 350 | 161 | 164 | 61 | 61 | Plain |
15378 | 3.2 | 0.0065 | 143.2 | 171 | 163 | 51 | 51 | Plain |
15379 | 5 | 0.0091 | 10.9 | 244 | 247 | 80 | 80 | Basket |
15403 | 4.7 | 0.0157 | 450 | 214 | 231 | 73 | 73 | Mock Leno |
15412 | 2.6 | 0.013 | 1000 | 88 | 83 | 30 | 29 | Plain |
15416 | 4.9 | 0.0095 | 19.5 | 217 | 204 | 69 | 70 | Twill |
15425 | 2.8 | 0.008 | 687 | 92 | 111 | 61 | 60 | Plain |
15435 | 16 | 0.0296 | 12.5 | 520 | 317 | 73 | 28 | Plain |
15438 | 11.1 | 0.0377 | 15 | 527 | 570 | 34 | 35 | Mock Leno |
15439 | 6 | 0.0131 | 69 | 329 | 353 | 75 | 74 | Basket |
15442 | 4.3 | 0.0074 | 15.3 | 194 | 145 | 70 | 51 | Plain |
15443 | 14.7 | 0.0392 | 10 | 730 | 895 | 40 | 50 | Mock Leno |
15449 | 3.5 | 0.0059 | 19.3 | 140 | 84 | 199 | 123 | Satin |
15451 | 5.4 | 0.0101 | 10 | 293 | 1272 | 93 | 87 | Basket |
15452 | 5.3 | 0.0096 | 10 | 298 | 286 | 92 | 87 | Basket |
15458 | 3.1 | 0.0045 | 2.4 | 201 | 133 | 182 | 80 | Plain |
15460 | 3.1 | 0.012 | 1500 | 176 | 114 | 49 | 29 | Leno |
15461 | 5.4 | 0.0112 | 180.6 | 254 | 277 | 78 | 85 | Basket |
15463 | 4.2 | 0.0138 | 1500 | 151 | 263 | 44 | 22 | Leno |
15468 | 3.8 | 0.014 | 1500 | 181 | 157 | 50 | 23 | Leno |
15470 | 3.9 | 0.0132 | 1500 | 216 | 212 | 51 | 25 | Leno |
15478 | 7.7 | 0.014 | 2.9 | 257 | 219 | 121 | 73 | Plain |
15497 | 6.7 | 0.0093 | 2.2 | 241 | 199 | 108 | 68 | Plain |
15505 | 4.6 | 0.0106 | 218.3 | 163 | 116 | 63 | 43 | Plain |
15510 | 8.6 | 0.0185 | 57 | 366 | 151 | 154 | 58 | Twill |
15511 | 2 | 0.0035 | 113.3 | 73 | 80 | 96 | 104 | Plain |
15512 | 5.2 | 0.01 | 30.4 | 214 | 134 | 72 | 56 | Plain |
15516 | 2 | 0.0072 | 1000 | 70 | 71 | 67 | 69 | Twill |
15528 | 9.1 | 0.0172 | 35.4 | 470 | 442 | 45 | 47 | Basket |
15530 | 8.9 | 0.0185 | 40 | 368 | 169 | 152 | 60 | Twill |
15531 | 8.8 | 0.0186 | 34 | 384 | 177 | 154 | 62 | Twill |
15533 | 8.4 | 0.0178 | 9.6 | 292 | 164 | 152 | 58 | Basket |
15549 | 1.2 | 0.0041 | 770.4 | 57 | 70 | 102 | 113 | Plain |
15556 | 4.9 | 0.0133 | 185.2 | 199 | 148 | 70 | 54 | Basket |
15576 | 1.9 | 0.0074 | 1000 | 72 | 69 | 67 | 64 | Basket |
15577 | 2 | 0.0052 | 299.6 | 72 | 76 | 67 | 65 | Plain |
15578 | 2 | 0.0063 | 700 | 66 | 74 | 67 | 65 | Plain |
15586 | 2 | 0.0051 | 108 | 71 | 72 | 96 | 101 | Plain |
15596 | 6.3 | 0.0118 | 16.6 | 315 | 199 | 108 | 68 | Satin |
15603 | 2.2 | 0.0047 | 109.3 | 108 | 100 | 104 | 108 | Plain |
15604 | 7.9 | 0.0205 | 275 | 565 | 612 | 22 | 23 | Plain |
15637 | 3.3 | 0.0096 | 192.6 | 93 | 85 | 70 | 67 | Plain |
15640 | 3.3 | 0.0098 | 100 | 114 | 100 | 71 | 65 | Plain |
15650 | 3.1 | 0.0117 | 1067.8 | 133 | 144 | 43 | 43 | Plain |
15654 | 15.8 | 0.0278 | 32.6 | 470 | 284 | 80 | 43 | Twill |
15658 | 3.4 | 0.0143 | 1500 | 151 | 222 | 39 | 25 | Leno |
15662 | 3.3 | 0.0075 | 244 | 229 | 146 | 57 | 47 | Plain |
15673 | 4.2 | 0.0055 | 1.48 | 164 | 99 | 235 | 103 | Twill |
15680 | 4.2 | 0.0147 | 495.2 | 217 | 225 | 66 | 68 | Mock Leno |
15681 | 3.8 | 0.0131 | 542.3 | 197 | 214 | 60 | 60 | Mock Leno |
15692 | 4.7 | 0.0135 | 39.8 | 149 | 140 | 217 | 97 | Satin |
15737 | 3.8 | 0.0074 | 9 | 161 | 106 | 234 | 99 | Twill |
15740 | 6.1 | 0.0142 | 4.8 | 394 | 365 | 51 | 50 | Basket |
15760 | 3 | 0.0042 | 34.7 | 211 | 67 | 53 | 52 | Plain |
15763 | 2.2 | 0.0074 | 972.9 | 96 | 79 | 63 | 43 | Plain |
15764 | 2 | 0.0075 | 1216.3 | 97 | 51 | 52 | 34 | Plain |
15769 | 3.4 | 0.0078 | 27.4 | 274 | 268 | 58 | 54 | Plain |
15780 | 2.4 | 0.0067 | 619.6 | 74 | 75 | 77 | 71 | Plain |
15782 | 3.4 | 0.0093 | 112 | 136 | 135 | 71 | 66 | Plain |
15783 | 5.8 | 0.012 | 105.6 | 263 | 122 | 64 | 36 | Satin |
15785 | 4.1 | 0.0099 | 81.6 | 235 | 220 | 65 | 62 | Twill |
15787 | 4.1 | 0.0101 | 79.2 | 234 | 220 | 65 | 61 | Satin |
15788 | 4.1 | 0.0093 | 27.5 | 240 | 228 | 65 | 62 | Chain |
15790 | 4.7 | 0.0063 | 1.6 | 199 | 344 | 51 | 96 | Basket |
15792 | 2.1 | 0.0055 | 571 | 228 | 30 | 62 | 38 | Plain |
15796 | 1 | 0.0038 | 700 | 45 | 39 | 90 | 89 | Plain |
15806 | 2.8 | 0.0061 | 50.8 | 398 | 31 | 81 | 41 | Plain |
15816 | 3.1 | 0.0058 | 3.1 | 34 | 426 | 47 | 90 | Plain |
15820 | 4.3 | 0.0094 | 51.8 | 200 | 101 | 204 | 91 | Satin |
15822 | 2.9 | 0.006 | 49.1 | 432 | 51 | 81 | 81 | Plain |
15823 | 2.1 | 0.0055 | 194.5 | 69 | 80 | 68 | 81 | Plain |
15828 | 7.6 | 0.0157 | 51 | 390 | 360 | 60 | 55 | Satin |
15834 | 2.9 | 0.0046 | 3.1 | 54 | 388 | 90 | 78 | Plain |
15838 | 5.9 | 0.0211 | 400 | 683 | 159 | 31 | 33 | Mock Leno |
15844 | 2.9 | 0.0078 | 388.3 | 255 | 88 | 68 | 24 | Plain |
15845 | 3.4 | 0.0072 | 8.9 | 276 | 62 | 77 | 89 | Plain |
15846 | 6.8 | 0.0121 | 2.7 | 360 | 346 | 53 | 48 | Plain |
15849 | 3 | 0.0062 | 29.9 | 174 | 166 | 48 | 45 | Plain |
15850 | 4.5 | 0.0075 | 66.9 | 204 | 90 | 56 | 50 | Satin |
15854 | 3 | 0.006 | 11.5 | 383 | 66 | 88 | 60 | Plain |
15871 | 6.8 | 0.0128 | 1.6 | 214 | 305 | 159 | 48 | Plain |
15872 | 5.1 | 0.012 | 58.3 | 31 | 37 | 77 | 78 | Basket |
15923 | 2 | 0.0061 | 763.5 | 56 | 56 | 70 | 67 | Plain |
15925 | 3.8 | 0.0099 | 117.3 | 185 | 217 | 52 | 64 | Twill |
15942 | 1.2 | 0.0043 | 795 | 34 | 31 | 99 | 98 | Plain |
15951 | 5.1 | 0.012 | 41.2 | 282 | 291 | 76 | 78 | Basket |
15954 | 1.2 | 0.0038 | 742.5 | 35 | 36 | 97 | 103 | Plain |
15957 | 7.5 | 0.0251 | 800 | 372 | 430 | 24 | 24 | Leno |
15959 | 1.3 | 0.0049 | 72.8 | 36 | 38 | 96 | 101 | Plain |
15964 | 5.5 | 0.0103 | 5.5 | 214 | 216 | 75 | 80 | Twill |
15972 | 1.9 | 0.0044 | 74.7 | 67 | 51 | 103 | 83 | Plain |
15977 | 3.3 | 0.0077 | 228.5 | 188 | 192 | 52 | 52 | Basket |
15983 | 7.7 | 0.0166 | 17.5 | 394 | 165 | 149 | 55 | Twill |
15987 | 3.3 | 0.0069 | 18.7 | 70 | 124 | 106 | 206 | Twill |
16017 | 8.9 | 0.0177 | 32.5 | 398 | 167 | 155 | 55 | Twill |
16045 | 2.8 | 0.0071 | 32.4 | 115 | 78 | 156 | 77 | Twill |
16052 | 2.7 | 0.0068 | 34.1 | 152 | 159 | 42 | 43 | Plain |
16054 | 9 | 0.0185 | 38 | 360 | 70 | 155 | 60 | Twill |
16056 | 2.9 | 0.0057 | 91.4 | 109 | 105 | 74 | 66 | Basket |
16062 | 6.1 | 0.0082 | 0.2 | 582 | 526 | 50 | 43 | Plain |
16063 | 3.6 | 0.0124 | 841 | 107 | 110 | 43 | 44 | Plain |
16066 | 6.7 | 0.0117 | 2.82 | 331 | 265 | 54 | 44 | Plain |
16067 | 13.3 | 0.0261 | 21.1 | 990 | 1036 | 38 | 37 | Basket |
16068 | 1.2 | 0.0043 | 866.7 | 37 | 34 | 97 | 95 | Plain |
16082 | 6.1 | 0.0081 | 0.15 | 513 | 548 | 48 | 46 | Plain |
16083 | 2.6 | 0.0043 | 4.6 | 109 | 64 | 164 | 92 | Twill |
16088 | 1.5 | 0.0082 | 1500 | 52 | 63 | 49 | 34 | Leno |
16090 | 3.1 | 0.006 | 16.7 | 106 | 76 | 171 | 81 | Twill |
16110 | 3.2 | 0.0051 | 1.8 | 94 | 74 | 170 | 94 | Plain |
16120 | 2.6 | 0.004 | 0.3 | 94 | 51 | 167 | 90 | Plain |
16121 | 2.3 | 0.0049 | 39.5 | 148 | 170 | 107 | 111 | Plain |
16124 | 4.4 | 0.0086 | 20 | 187 | 153 | 63 | 52 | Plain |
16125 | 3 | 0.0061 | 10.7 | 161 | 162 | 153 | 148 | Basket |
16130 | 4.6 | 0.0085 | 11.6 | 199 | 158 | 70 | 55 | Plain |
16131 | 5.8 | 0.0075 | 0.12 | 451 | 434 | 47 | 45 | Plain |
16133 | 5.4 | 0.0074 | 0.3 | 459 | 431 | 46 | 44 | Plain |
16136 | 2.2 | 0.0054 | 136.6 | 64 | 59 | 106 | 104 | Plain |
16143 | 7.5 | 0.019 | 17 | 477 | 589 | 25 | 28 | Plain |
16154 | 2.9 | 0.0058 | 27.3 | 402 | 76 | 79 | 35 | Plain |
16221 | 2.08 | 0.0051 | 116.5 | 75 | 74 | 102 | 104 | Plain |
16222 | 1.96 | 0.0043 | 33.9 | 75 | 68 | 102 | 100 | Plain |
16224 | 1.91 | 0.0068 | 754.8 | 67 | 66 | 69 | 64 | Plain |
16226 | 7.2 | 0.0217 | 900 | 352 | 417 | 24 | 24 | Leno |
16232 | 0.9 | 0.0065 | 1500 | 52 | 42 | 51 | 34 | Leno |
16236 | 4.56 | 0.0083 | 5.29 | 219 | 186 | 70 | 57 | Plain |
16238 | 4.89 | 0.0089 | 2.45 | 158 | 249 | 234 | 71 | Satin |
16239 | 0.87 | 0.0041 | 1500 | 47 | 36 | 87 | 54 | Leno |
16240 | 1.22 | 0.0046 | 999.4 | 48 | 47 | 99 | 100 | Plain |
16241 | 1.8 | 0.0054 | 403.3 | 57 | 59 | 157 | 85 | Dobby |
16243 | 4.07 | 0.0085 | 11.7 | 260 | 217 | 67 | 59 | Plain |
16244 | 6.52 | 0.0131 | 2.63 | 446 | 462 | 100 | 50 | Plain |
16245 | 5.66 | 0.0014 | 96.5 | 191 | 107 | 65 | 76 | Satin |
16246 | 6.71 | 0.0149 | 22.2 | 273 | 276 | 64 | 65 | Basket |
16247 | 3.07 | 0.007 | 159 | 195 | 175 | 52 | 51 | Plain |
16248 | 4.14 | 0.011 | 149 | 239 | 244 | 70 | 66 | Basket |
16249 | 4.33 | 0.015 | 512.4 | 285 | 212 | 74 | 72 | Mock Leno |
16251 | 2.82 | 0.0122 | 1500 | 140 | 218 | 35 | 22 | Leno |
16253 | 4.49 | 0.0112 | 147.6 | 233 | 163 | 74 | 72 | Basket |
17004 | 7.23 | 0.0149 | 1.51 | 443 | 702 | 41 | 81 | Plain |
17009 | 2.69 | 0.0067 | 244.8 | 135 | 160 | 119 | 74 | Twill |
17021 | 4.46 | 0.011 | 94.1 | 276 | 260 | 78 | 76 | Basket |
